QO(B) circuit breakers come in plug-on or bolt-on options and a complete range of amperages and interrupting ranges to fit into various QO distribution panels. QO is the “World’s Finest” Industry leading offer since 1955, with features engineered for faster installation, reliability and quality.
Specifications
- Product: Miniature circuit-breaker
- Range: QO
- Current Rating: 20 A
- Inturrupt Rating: 10 kA 120/240 V AC 50/60 Hz, 10 kA 120 V AC 50/60 Hz, 5 kA 48 V DC
- Certifications: UL listed, CSA
- Voltage Rating: 120/240 V AC, 120 V AC, 48 V DC
- Mounting Type: Plug-in
- Number of Poles: 2
- Number of Panel Spaces: 2
- Circuit Breaker Type: Standard
- Ratings: HACR rated
- Electrical Connection: Pressure plate
- Wire Size: AWG 14...AWG 8 copper or aluminium
- Warranty: 18 months
