The AG130-001, dual inlet air gap is designed to simultaneously provide water discharge from a water softener and reverse osmosis (RO) water filter. The combination of water softener drain and RO drain provides a simple solution for accommodating both devices. The water softener port accepts 5/8" OD poly tubing, 1/2" PVC slip pipe, and 1/2" or 5/8" ID poly tubing. The RO port accepts 3/8-inch OD poly tube directly and 1/4" OD poly tube with 3/8 tube adapter
This air gap is easy to install and fits both 1-1/2" and 2" standpipe. The AG130-001 air gap is listed by UPC and tested for compliance with IPC and NSF standards.
Features
- Easy to use, space-saving two in one air gap
- Water Softener port is 1/2" slip or 5/8" OD poly tube
- RO port accepts 3/8" or 1/4" OD poly tube
- Includes 1/2" inlet elbow with flow straightener
- Flow rate capability 0.1 to 7.0 gallons/minute
- UPC® listed, tested for compliance to IPC® and NSF® standards
