For the installation and protection of electrical conductors in circuits of 600 volts nominal, or less
Motor circuits - for conductors of motor feeders, branch and control circuits
Where the conditions of installation, operation, or maintenance require flexibility or protection from liquids, vapors, solids, or weather
Agricultural buildings per NEC® 547.5
Used in industrial and commercial applications for conveyors, blowers, cranes, air conditioners, machine tooling and lubrication equipment
Exposed or concealed installations
Applications requiring movement, crossover connections, or tight bends
For direct burial and encased in concrete
For flexible connections to swimming pool, spa and hot tub motors per NEC® 680.21(A)(3) & 680.42(A)(1)
Electric signs and outline lighting supply and secondary-circuit conductors per NEC® 600.7, 600.31 (1000 volts or less) & 600.32 (over 1000 volts)
Hazardous Locations - see Additional Applications Section on the following page for more details
Features:
A protective combination of thermoplastic materials formed into a conduit/raceway which seals out water, liquids, abrasives, alcohol, coolants, corrosive fumes and gases, dirt, grease, mineral acids, non-concentrated fixed alkalines, petroleum oils, salt air and spray and weather
Smooth interior for easy wire pulling
UV sunlight-resistant jacket
Rated for temperature range of -30°C to +80°C, 60°C Oil (-22°F to +176°F, 140°F Oil)
Accepts standard Liquidtight fittings for use with LFNC-B
Specs
Size:
3/4"
Material:
Non-Metallic
Length (Feet):
100'
Color:
Gray
SKU:CTD-000442
Regular price
$108.00
Regular priceSale price
$108.00
Sale
Sold out
In stock
